Honeywell 10313/1/1 5V DC & Watchdog Distribution Module

Product Overview

As a maintenance engineer, you know that in a safety-critical FSC (Fail-Safe Control) system, every component must perform flawlessly. The Honeywell 10313/1/1 is the backbone of your 5 V DC and watchdog (WD) signal distribution. This module ensures that your redundant and non-redundant I/O backplanes receive clean, reliable power and that the watchdog signals—vital for system health monitoring—are properly routed. Designed for the FSC system, the 10313/1/1 simplifies wiring, reduces points of failure, and is built to the highest industrial standards.

Whether you are upgrading an existing FSC system or replacing a failed module, the 10313/1/1 offers a direct, drop-in solution. Its robust construction and clear connector layout make installation and troubleshooting straightforward, minimizing downtime. With CE and TÜV approvals, you can trust this module to meet stringent safety requirements.

Key Features

• Redundant and Non-Redundant Support: Ten connectors (RCN-1 to RCN-10) for redundant I/O backplanes (10315/1/1) and ten connectors (SCN-1 to SCN-10) for non-redundant backplanes (10314/1/1).
• Flexible Power Inputs: Dedicated faston connectors for both redundant and non-redundant 5 V DC power sources, ensuring proper power distribution.
• Direct Watchdog Connections: Connectors for watchdog repeaters (WDRs) and 10005/O/2 WD horizontal buses, simplifying system integration.
• Expandable Design: Connectors for linking an additional 10313/1/1 module in a separate cabinet, allowing for system expansion.
• Compact and DIN Rail Mountable: Fits on TS32 / TS35 x 7.5 rails, saving cabinet space and simplifying installation.
• High Reliability: CE and TÜV approved, with no additional current consumption (power is supplied via I/O modules).

Technical Specifications

| Parameter | Value |

|-----------|-------|

| Type Number | 10313/1/1 207011 |

| Approvals | CE, TÜV (UL pending) |

| Current Consumption | None (included in I/O module data sheets) |

| Max. Current on Faston Pin | 4 A |

| Max. Current on I/O Connector Pin | 2 A |

| Dimensions (L x W x H) | 240 x 87 x 60 mm (9.45 x 3.43 x 2.36 in) |

| DIN EN Rails | TS32 / TS35 x 7.5 |

| Used Rail Length | 241 mm (9.49 in) |

Note: 10313/1/1 modules with suffix code 20700 have a different connector layout. Please verify compatibility before ordering.

Applications

The Honeywell 10313/1/1 is essential for any FSC system used in critical industrial processes. Typical applications include:

• Process Safety Systems: Emergency shutdown (ESD), fire and gas detection, and burner management systems.
• Oil & Gas: Offshore platforms, refineries, and pipeline control systems.
• Chemical & Petrochemical: Reactor protection and safe process control.
• Power Generation: Turbine control and safety systems.
• Water Treatment: Disinfection and chemical dosing safety interlocks.

By ensuring reliable 5 V DC distribution and watchdog signal integrity, the 10313/1/1 helps maintain the high availability and safety integrity level (SIL) of your FSC system.
