KEB 09F5C1B-3A0A Frequency Inverter – Reliable Drive for Industrial Applications

Product Overview

The KEB 09F5C1B-3A0A is a high-performance frequency inverter from the renowned COMBIVERT F5 series. Designed to deliver precise motor control and energy efficiency, this 1.5 kW drive operates on a 3-phase 400 VAC input and provides an output of 0-480 VAC with a frequency range of 0-800 Hz. Its robust construction and advanced features make it suitable for a wide range of industrial applications, including conveyors, pumps, fans, and machine tools.

As part of the F5 Combivert Axis Drive Series, the 09F5C1B-3A0A is engineered for reliability and flexibility. It supports multiple feedback devices (resolver, incremental encoder, Sin/Cos encoder, absolute encoder) and offers comprehensive monitoring functions such as short-circuit and earth fault protection. With an IP20 enclosure, it is ideal for installation in control cabinets within controlled indoor environments.

Key Features

• Power Rating: 1.5 kW – suitable for a variety of light-to-medium duty applications.
• Input: 3-phase 400 VAC, 5.7 A, 50/60 Hz – compatible with standard industrial power supplies.
• Output: 0-480 VAC, 0-800 Hz, 4.1 A – provides wide speed and torque control range.
• Feedback Options: Supports resolver, incremental encoder, Sin/Cos encoder, and absolute encoder for precise motor control.
• Safety Monitoring: Short-circuit and earth fault monitoring enhance operational safety.
• Compliance: Meets EN 61800-2, EN 61800-5-1, and EN 61800-3 (EMC) standards.
• Enclosure: IP20 rated – suitable for indoor, cabinet-mounted installations.
• Temperature Range: Operating -10 to 45 °C; storage -25 to 70 °C – durable across varied conditions.
• Switching Frequency: 8/16 kHz – allows optimized motor acoustics and reduced harmonics.
• Communication: Potential-free operator connection and serial interfaces for easy integration.

Technical Specifications

| Parameter | Value |

|------------|-------|

| Part Number | 09F5C1B-3A0A |

| Brand | KEB |

| Series | COMBIVERT F5 |

| Product Type | Frequency Inverter |

| Power Rating | 1.5 kW |

| Input Voltage | 3-phase 400 VAC |

| Input Current | 5.7 A |

| Input Frequency | 50/60 Hz |

| Output Voltage | 0-480 VAC |

| Output Current | 4.1 A |

| Output Frequency | 0-800 Hz |

| Max. Current (Iₘₐₓ) | 8.9 A |

| Enclosure Type | IP20 |

| Operating Temp. | -10 to 45 °C |

| Storage Temp. | -25 to 70 °C |

| Switching Frequency | 8/16 kHz |

| Feedback Support | Resolver, Incremental, Sin/Cos, Absolute |

| Earth Fault Monitoring | Yes |

| Short-circuit Monitoring | Yes |

| Serial Interfaces | Available |

| Potential-free Operator Connection | Yes |

| Standards | EN 61800-2, EN 61800-5-1, EN 61800-3 |

| Dimensions (H×W×D) | 22 cm × 9 cm × 16 cm (8.6 × 3.5 × 6.2 in) |

| Weight | 2 kg (4.4 lbs) |

Applications

The KEB 09F5C1B-3A0A is a versatile drive suitable for many industrial sectors, including:

• Material Handling: Conveyors, elevators, and hoists.
• HVAC: Fans, pumps, and compressors.
• Machine Tools: Spindles, feed drives, and auxiliary axes.
• Packaging: Filling, sealing, and labeling machines.
• Textile: Spinning, weaving, and finishing equipment.
• Automotive: Assembly lines and test stands.

Its robust design and flexible feedback options make it an excellent choice for applications requiring precise speed and torque control, as well as for retrofitting older machinery.

Why Choose UbestNine?

At UbestNine, we specialize in providing high-quality new and refurbished industrial automation parts. Here’s why customers trust us:

• Quality Assurance: Every product is tested to meet original specifications.
• Competitive Pricing: We offer affordable options without compromising on performance.
• Fast Shipping: In-stock items ship within 24 hours.
• Expert Support: Our knowledgeable team helps you select the right part for your needs.
• Warranty: All products come with a warranty for peace of mind.

Whether you need a replacement drive or are building a new system, UbestNine is your reliable partner for industrial automation components.

Comparison with Similar Products

| Feature | KEB 09F5C1B-3A0A | Typical 1.5 kW Drive | Typical 2.2 kW Drive |

|----------|------------------|----------------------|----------------------|

| Input Voltage | 3-phase 400 VAC | 3-phase 400 VAC | 3-phase 400 VAC |

| Output Current | 4.1 A | ~4 A | ~5.5 A |

| Max. Current | 8.9 A | ~8 A | ~10 A |

| Feedback Options | Resolver, Encoder, etc. | Basic (often no encoder) | Optional |

| Switching Frequency | 8/16 kHz | 4-8 kHz | 4-8 kHz |

| Enclosure | IP20 | IP20 | IP20 |

| Standards | EN 61800-2/5-1/3 | EN 61800-2/5-1 | EN 61800-2/5-1 |

This comparison highlights the KEB drive’s advanced feedback capabilities and higher switching frequency, making it a superior choice for applications requiring dynamic response and precise control.

FAQ

Q: What is the input voltage and frequency for the KEB 09F5C1B-3A0A?

A: The drive accepts 3-phase 400 VAC at 50/60 Hz.

Q: What is the output frequency range?

A: The output frequency can be adjusted from 0 to 800 Hz.

Q: Does this drive support encoder feedback?

A: Yes, it supports resolver, incremental encoder, Sin/Cos encoder, and absolute encoder feedback.

Q: What is the degree of protection?

A: The enclosure is rated IP20, suitable for indoor cabinet installation.

Q: Is the drive compliant with safety standards?

A: Yes, it meets EN 61800-2, EN 61800-5-1, and EN 61800-3 (EMC) standards.

Q: Can I use this drive for pump and fan applications?

A: Absolutely, it is well-suited for variable torque loads like pumps and fans.

Q: What is the maximum current rating?

A: The maximum current (Iₘₐₓ) is 8.9 A.

Q: Does UbestNine offer a warranty on this product?

A: Yes, all products come with a warranty. Contact us for details.

Q: What is the switching frequency range?

A: The switching frequency can be set to 8 kHz or 16 kHz.

Q: What are the storage temperature limits?

A: The drive can be stored at temperatures between -25 °C and 70 °C.

Ordering Information

To order the KEB 09F5C1B-3A0A or to inquire about availability, please contact our sales team. We offer both new and refurbished units, all thoroughly tested and backed by our warranty. Visit our website or call us today to get a quote.
