KEB 07F5A1A-3E2F F5 Combivert Axis Drive – Compact Precision for Your Automation Needs

Product Overview

The KEB 07F5A1A-3E2F is a member of the KEB F5 Combivert Axis Drives series, engineered to deliver reliable and precise control in a space-saving package. With a rated power of 0.75 kW, this drive handles a rated current of 2.6 A and a maximum current of 4.7 A, making it ideal for small-scale automation tasks that demand accuracy and efficiency. Its compact design allows for easy integration into existing systems, while its robust construction ensures long-term performance in controlled indoor environments.

This drive is designed to meet the needs of modern industrial applications, offering flexible modulation frequencies (8/16 kHz) to reduce electromagnetic interference and comply with EMC standards EN 61800-3 and EN 61000-6. The IP20 protection rating makes it suitable for use in clean, dry environments where protection against solid objects is required but water ingress is not a concern. With an operating temperature range of -10°C to +45°C and storage from -25°C to +70°C, the 07F5A1A-3E2F is built to perform consistently.

Whether you are upgrading an existing system or designing a new one, the KEB 07F5A1A-3E2F offers a versatile and cost-effective solution for a wide range of automation tasks.

Key Features

• Compact and Versatile: Space-efficient design suitable for a variety of automation applications.
• Precise Current Control: Rated current of 2.6 A and maximum current of 4.7 A for accurate motor control.
• Flexible Switching Frequencies: 8/16 kHz modulation reduces electromagnetic interference, enhancing system stability.
• EMC Compliance: Meets EN 61800-3 and EN 61000-6 standards; built-in filter complies with EN 55011/C1.
• IP20 Protection: Suitable for controlled indoor environments, protected against solid objects.
• Robust Thermal Management: Air-cooled system maintains operation between -10°C and +45°C.
• Wide Voltage Range: Operates on 3-phase systems from 305 to 528 VAC.
• Advanced Safety Features: Includes 2-channel optocoupler braking, ISO 13849 compliance, and SIL 3 per IEC 62061.
• Short-Circuit and Earth Fault Monitoring: Complies with EN 60204-1 for enhanced safety.
• Optional Harmonic Filter: Available to meet international standards and reduce disruptions.

Technical Specifications

| Parameter | Value |

|-----------|-------|

| Rated Power | 0.75 kW |

| Rated Current | 2.6 A |

| Maximum Current | 4.7 A |

| Switching Frequency | 8/16 kHz |

| Voltage Class | 305 to 528 VAC |

| Phase | 3 |

| Protection Class | IP20 |

| Cooling Method | Air-cooled |

| Operating Temperature Range | -10°C to +45°C |

| Storage Temperature Range | -25°C to +70°C |

| EMC Standard Compliance | EN 61800-3, EN 61000-6 |

| Integrated Filter | Complies with EN 55011/C1 |

| Safety Features | ISO 13849, SIL 3 per IEC 62061 |

| Short-Circuit and Earth Fault Monitoring | EN 60204-1 |

| Warranty | One year |

Applications

The KEB 07F5A1A-3E2F is well-suited for a variety of industrial applications, including:

• Material Handling: Conveyors, hoists, and lifts requiring precise speed and torque control.
• Packaging Machinery: Accurate positioning and synchronization in packaging lines.
• Textile Machinery: Consistent speed control for spinning, weaving, and knitting equipment.
• Food and Beverage: Pumps, mixers, and fillers that demand hygienic and reliable operation.
• HVAC Systems: Fans, blowers, and compressors needing efficient variable speed control.
• Machine Tools: Spindle drives and feed axes in CNC machines.
• Automotive Industry: Assembly lines and robotic systems requiring high precision.
• Pumps and Fans: General industrial applications where energy savings and process control are key.

Why Choose UbestNine?

At UbestNine, we specialize in providing high-quality new and refurbished industrial automation parts. Here’s why customers trust us:

• Quality Assurance: Every product is tested to ensure it meets original specifications and performance standards.
• Competitive Pricing: We offer cost-effective solutions without compromising on quality.
• Fast Shipping: Our extensive inventory allows for quick dispatch and delivery.
• Expert Support: Our knowledgeable team is ready to help you find the right part for your application.
• Warranty: All products come with a one-year warranty for peace of mind.

Whether you need a replacement drive or are planning a new installation, UbestNine is your reliable partner for automation components.

Comparison with Similar KEB Drives

| Model | Rated Power | Rated Current | Max Current | Protection | Switching Frequency |

|-------|-------------|---------------|-------------|------------|---------------------|

| 07F5A1A-3E2F | 0.75 kW | 2.6 A | 4.7 A | IP20 | 8/16 kHz |

| KEB F5 (typical larger model) | 1.5 kW | 4.0 A | 7.5 A | IP20 | 8/16 kHz |

| KEB F5 (typical smaller model) | 0.37 kW | 1.2 A | 2.0 A | IP20 | 8/16 kHz |

Note: Comparison values are based on typical KEB F5 series models and may vary. Always check the specific datasheet for exact specifications.

Frequently Asked Questions

What is the warranty period for the KEB 07F5A1A-3E2F?

All products from UbestNine, including the KEB 07F5A1A-3E2F, come with a one-year warranty against defects in materials and workmanship.

Can this drive be used in outdoor environments?

No, the IP20 protection rating makes it suitable only for controlled indoor environments where it is protected against solid objects but not water. For outdoor use, a higher IP-rated enclosure would be required.

What are the EMC compliance standards for this drive?

The drive complies with EN 61800-3 and EN 61000-6, and the integrated filter meets EN 55011/C1 requirements, ensuring reduced electromagnetic interference.

Does the drive support safety functions?

Yes, it includes built-in 2-channel optocoupler braking that complies with ISO 13849 and provides SIL 3 as per IEC 62061, enhancing operational safety.

What is the operating temperature range?

The drive operates between -10°C and +45°C, with storage temperatures from -25°C to +70°C, making it suitable for a variety of indoor environments.

Ordering Information

To purchase the KEB 07F5A1A-3E2F or to inquire about availability, contact UbestNine today. Our team is ready to assist you with your automation needs.

Note: Specifications are subject to change without notice. Please refer to the official KEB documentation for the most current information.
